Drone Battery's Charger
Using high-frequency power supply and smart dynamic adjustment technology, supports multi-protocol fast charging, with integrated over-voltage and over-temperature protection, and real-time monitoring of the charging status. Compatible with drone batteries, featuring multi-channel output and precision craftsmanship. A scientific quality control system ensures stable and safe performance, offering professional OEM/ODM smart charger solutions for efficient and secure charging.
Highlights:
- Multi-channel output
- High-efficiency fast charging
- Smart recognition
- Real-time monitoring
- Multiple protections
ยท 68.4V 18S1P configuration with 30000mAh capacity and 2052Wh nominal energy
ยท Stable 15C continuous discharge supports takeoff and changing UAV loads
ยท Up to 3C charging supports practical battery rotation for repeated operations
ยท 10200g soft pack design balances high-voltage energy with UAV integration
ยท Cycle life of at least 750 cycles under specified operating conditions
ยท 200000W high-power charging platform for industrial UAV batteries
ยท Supports 14S to 28S LiPo and LiHV drone battery packs
ยท Dual-channel output with up to 200A maximum current per channel
ยท AC 260-520V high-voltage input for industrial power environments
ยท QS10 output connector for high-current UAV battery charging
ยท 104000W high-power charging platform for industrial UAV batteries
ยท Supports 18S to 32S LiPo and LiHV drone battery packs
ยท Dual-channel output with up to 120A charging current per channel
ยท AC 90-290V wide voltage input for global power environments
ยท QS9 output connector for high-current UAV battery charging
ยท 72000W industrial charging platform for 18S UAV batteries
ยท Dual-channel output with up to 96A charging current per channel
ยท Supports 18S LiPo and 18S LiHV drone battery packs
ยท AC 90-290V wide voltage input for global power environments
ยท Rack-mount frame design for centralized industrial UAV charging
ยท Single channel max charging current up to 60A
ยท Suitable for 12-14S LiPo and LiHV UAV batteries
ยท AC220V 50-60Hz input for industrial charging workflows
ยท AS150U-M output plug for UAV battery charging applications
ยท 2 channel charger with total power up to 7200W
ยท Single channel max charging current up to 96A
ยท Wide AC100-290V input for more flexible charging deployment
ยท Suitable for 14-18S LiPo and LiHV UAV batteries
ยท T50-300 output plug for high-power UAV charging applications
Applications
Supports multi-channel fast charging to minimize downtime and ensure on-time deliveries, with real-time battery health monitoring.
Intelligently detects battery status and adjusts charging strategy based on operational intensity, enabling efficient rotation for multi-drone fleets.
Features low-temperature preheating for reliable charging in harsh outdoor conditions, with real-time alerts for charging anomalies.
FREE DESIGN
Customized exclusive battery plans! Professional engineers plan battery programs one-on-one.
Maximize Drone Effect with Our Tailored Battery Solutions
Explore Herewin Factory: The Source of Quality
Founded in 2019, Shenzhen Jarwin Time Technology Co., Ltd. is backed by a founding and operational team with over 20 years of extensive experience in the battery industry. It specializes in developing and producing high-performance lithium-ion polymer batteries.
Gain a comprehensive insight into who we are and what we stand for. By exploring the meticulous precision of our
production lines, the efficient management of our factories, and the genuine feedback from our satisfied customers,
youโll see how we ensure excellence at every step of the process
Different Services For Clients With Different Patterns
FOR OFFLINE CLIENTS
Flexible Delivery Time
Reliable delivery schedules and warehousing support.
High Cost-Effectiveness
Competitive pricing to maximize overall value.
Wide Product Selection
Diverse options to cater to all market segments.
FOR ONLINE CLIENTS
Low MOQ
Flexible MOQ with mixed product options.
Custom Logo
Personalized logo customization for small batches.
One-Stop Marketing Package
Provide quality images, videos to enhance sales revenue.
FOR BRAND CLIENTS
Exclusive Regional Rights
Provide all of herewin's resources and capabilities
R&D Resources
Custom sample within 7 days with R&D capabilities.
Fast Delivery
Efficient production and ship within 25 days at the fastest.
Production Flow of Drone Battery
Open packaging and sort materials.
Full inspection of grouped cells for defects: leakage, scratches, dents, punctures, swelling, improper foam alignment (exposed tabs or missing bottom foam).
Measure cell voltage and internal resistance; screen and rebalance cells with excessive deviations.
Trim electrode tabs to specification using a tab-cutting machine.
Weld tabs with an ultrasonic welder and trim to ensure flush alignment.
Trim tabs flush with weld points and press flat onto foam padding.
Solder wires using an electric iron.
Place kraft paper for insulation and cover with high-temperature adhesive tape.
Install battery module into casing per assembly specs and connect wiring.
Connect module to charger, switch to standard voltage mode, activate slow charge, and initiate charging.
Apply sealant to screw holes, install groove-down silicone plugs, and reinforce sealing at designated points.
Verify communication, output voltage, temperature sensing, discharge curves, and leakage.
Inspect for scratches, adhesive residue, stripped screws, and ensure labels are legible/undamaged.
Label units, place in foam-lined boxes, seal in PE bags with desiccant, and secure with top foam padding.
Box approved units and dispatch.
LEARN MORE DETAIL
Learn more about production details and manufacturing process
Testing Process
Fair&Certification
Certifications are herewin’s greatest strength.
Meets the needs of all markets, and the source factories are fully certified to ensure quality
Get In Touch With Us
Want to know what credentials your market needs? Contact me to send you a high resolution image
FAQs
Drone batteries must align with mission-specific demands:
-
Agricultural Spraying Drones: Require high-capacity batteries (8,000mAh+) for extended operation, paired with fast-charging capabilities, high-current discharge, and lightweight design.
-
Aerial Photography Drones: Prioritize compact, lightweight pouch-type polymer Li-ion batteries with extended flight time.
-
High-Speed Acrobatic Drones: Demand high discharge-rate batteries to sustain rapid acceleration bursts and stable power output.
-
Security/Mapping/Firefighting Drones: Focus on batteries with long endurance, temperature resilience, and durability across repeated cycles.
Reduced Performance in Cold Weather
-
Pre-warm batteries before use.
-
Limit flight time to half of normal duration in low temperatures.
-
Raise voltage alarm thresholds to prevent premature shutdowns.
Short Circuit Risks
-
Transport batteries in explosion-proof cases.
-
Avoid simultaneous contact of tools with positive/negative terminals during maintenance.
Casing Damage
-
Handle with care; secure straps before flight.
-
Retire batteries immediately if outer layers are compromised.
Mixing Batteries/Improper Charging
-
Never combine old and new batteries.
-
Avoid parallel charging of mismatched battery models.
Charging Protocol
-
Use manufacturer-approved chargers.
-
Prevent overcharging; perform balance charging periodically.
Storage Guidelines
-
Maintain 40-60% charge for long-term storage.
-
Store in a cool, dry environment (15-25ยฐC / 59-77ยฐF).
Usage Precautions
-
Avoid deep discharges (never drain below 20%).
-
Inspect for swelling, leaks, or damage post-flight.
Protective Measures
-
Keep batteries dry and shielded from corrosive substances.
-
Clean contacts and surfaces after each mission.
